RQG-N 3/8'' NPT FLEXAquick straight connector for 13.0 mm OD conduit
5020.056.203

Description


3/8'' NPT FLEXAquick® straight connector for 13.0 mm OD conduit NW 10, outer thread

NO tools required! Installs in seconds. Makes a reliable, liquidtight, conduit fitting installation, simple and quick.

The built-in FLEXAquick® connector release clip simplifies conduit and connector assembly for Quick "on" connect, Quick "off" disconnect.

Use with all corrugated plastic conduits of matching outside diameter (OD). Fine ("T" profile) or coarse ("G" profile) corrugations.

Need a different size?:  Browse other RQG-N NPT threaded straight fittings

Material:

  • plastic PA 6 polyamide nylon body, VO acc. to UL94
  • internal seal: TPE rubber

Properties:

  • IP 68 / IP 69K sealing level
  • Temperature range: -40ºC to +120ºC
  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Quick Link to our: Short Form FLEXAquick® Catalogue

Quick Links to other Products:



Specifications

Connector Thread:
3/8" NPT
Sealing Level:
IP68
Colour:
Black
Weight:
0.0054 kg
Package quantity:
50

Dimensions:
φ I:
10.00
φ B:
20.00
C:
8.50
D:
35.00
Conduit OD:
13.0 mm

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
UL1696
UL 1696
#E86359
E162 & 662
SMP800C
EN 45545-2 HL2 for R22 / R 23
45545-2
HL2 Rated
NFF 16-
101/102 I3

Alternate SKU Numbers

796253-3 | 5020-056-203 | 5020056203 | 5020 056 203 | 5020_056_203 | 5020/056/203 | 5020,056,203 | 5020+056+203
