10.0 mm OD black ROHRflex® Corrugated plastic conduit end sleeve NW 7, made of polyamide

Details:

• Handy end sleeve protects exiting cables, wires and air lines from the sharp edge of a cut conduit.
• Use with all corrugated plastic conduits of matching outside diameter (OD). Fine ("T" profile) or coarse ("G" profile) corrugations

Dimensions: (see attached drawing)

Need a different size?:  Browse other RQA conduit end sleeves

Material:

• temperature range: -40ºC to +120ºC
• made of black PA 6 polyamide nylon plastic
• VO acc. to UL94

Properties:

• resistant to oils and benzene
• widely resistant to acids and solvents

Use with ROHRflex® corrugated conduits

Quick Link to our: Short Form FLEXAquick® Catalogue
