FR-M M12 Metric Flat Buna-N Rubber Sealing Washer
0333.000.012
Description
M12 Metric Flat Buna-N Rubber Sealing Washer
Provides environmental sealing protection for all plastic or metal M12 x 1.5 mm Metric threaded conduit fittings, hose fittings, cable glands, strain reliefs, and cord grips.
Dimensions:
- Inside Diameter: Ød = 12.0 mm
- Outside Diameter: ØD = 20.0 mm
- Thickness: S = 1.5 mm
Need a different size?: Browse other FR-M Metric Buna-N Sealing Washers
Material:
- made of Buna-N , nitrile rubber
- Durometer Rating: Shore A 65 +/- 7
Properties:
- temperature rating: -20ºC to +100, short term to +120ºC
- resistant to oils and benzene
- widely resistant to acids and solvents
- Protects and seals Metric threaded fittings & glands from water and dirt ingress.
Use with all Metric threaded FLEXA & FLEXAquick® fittings
Specifications
Color:
Black
Weight:
0.0005 kg
Package Quantity:
50
Datasheet
Alternate SKU Numbers
796256-2 | 0333-000-012 | 0333000012 | 0333 000 012 | 0333_000_012 | 0333/000/012 | 0333,000,012 | 0333+000+012
