FR-M M20 Metric Flat Buna-N Rubber Sealing Washer
0333.000.020

Description

M20 Metric Flat Buna-N Rubber Sealing Washer

Provides environmental sealing protection for all plastic or metal M20 x 1.5 mm Metric threaded conduit fittings, hose fittings, cable glands, strain reliefs, and cord grips.

Dimensions:

  • Inside Diameter: Ød = 20.0 mm
  • Outside Diameter: ØD = 29.0 mm
  • Thickness: S = 2.0 mm

Need a different size?:  Browse other FR-M Metric Buna-N Sealing Washers

Material:

  • made of Buna-N , nitrile rubber
  • Durometer Rating: Shore A 65 +/- 7

Properties:

  • temperature rating: -20ºC to +100, short term to +120ºC
  • resistant to oils and benzene
  • widely resistant to acids and solvents
  • Protects and seals Metric threaded fittings & glands from water and dirt ingress.

Use with all Metric threaded FLEXA & FLEXAquick® fittings

Specifications

Color:
Black
Weight:
0.00087 kg
Package Quantity:
50

Datasheet

PDF iconfr.pdf

Alternate SKU Numbers

796256-4 | 0333-000-020 | 0333000020 | 0333 000 020 | 0333_000_020 | 0333/000/020 | 0333,000,020 | 0333+000+020
