FR-M M40 Metric Flat Buna-N Rubber Sealing Washer
0333.000.040

Description

M40 Metric Flat Buna-N Rubber Sealing Washer

Provides environmental sealing protection for all plastic or metal M40 x 1.5 mm Metric threaded conduit fittings, hose fittings, cable glands, strain reliefs, and cord grips.

Dimensions:

  • Inside Diameter: Ød = 40.0 mm
  • Outside Diameter: ØD = 52.0 mm
  • Thickness: S = 2.0 mm

Need a different size?:  Browse other FR-M Metric Buna-N Sealing Washers

Material:

  • made of Buna-N , nitrile rubber
  • Durometer Rating: Shore A 65 +/- 7

Properties:

  • temperature rating: -20ºC to +100, short term to +120ºC
  • resistant to oils and benzene
  • widely resistant to acids and solvents
  • Protects and seals Metric threaded fittings & glands from water and dirt ingress.

Use with all Metric threaded FLEXA & FLEXAquick® fittings

Specifications

Color:
Black
Weight:
0.00217 kg
Package Quantity:
25

Datasheet

PDF iconfr.pdf

Alternate SKU Numbers

796256-7 | 0333-000-040 | 0333000040 | 0333 000 040 | 0333_000_040 | 0333/000/040 | 0333,000,040 | 0333+000+040
