FLEXAgraff®-CU-PU-AS 11.0 x 15.0 mm metal conduit with tinned copper braid and PU jacket EMC rated to 30 MHz
2540.707.011

Description

OD 14.0 mm Flexa Protective EMC Rated flexible metal conduit with tinned copper wire braiding and a (PU) Polyurethane Jacket

Up to 80 dB and 30 MHz EMC screening attenuation! Rugged, liquidtight, no-stretch, flexible; all sealed in a green polyurethane sheathing.

Need another size? See other FLEXAgraff®-CU-PU-AS green PU jacketed liquidtight EMC rated conduits here:

Material & Structure:

  • strip-wound galvanized steel
  • "U" shaped profile, double overlapped folding, round cross-section
  • tinned copper wire braid
  • Polyurethane (PU) sheathing for excellent all-environment protection
  • Rated V2 according to UL 94

Properties:

  • IP 68 sealing level

  • -50ºC to +100ºC .... short term +130°C, wide application temperature range

  • high EMC shielding factor up to 30 MHz according to EN 50298-1-6 up to 80 dB
  • use brass thrust collar for full EMC safe assembly
  • high tensile and anti-twisting strength
  • highly flexible
  • good compression strength
  • stretch resistant
  • approved to DIN EN IEC 61386-23

Applications:

Excellent for cable & wire protection where EMC shielding is a must.

EMC shielding for applications including: robot servo-wiring, railway control equipment cabling, metering & measuring apparatus cabling, communication equipment wiring, process control & automation wiring.

Custom Deliveries:

  • Full metre lengths beginning with one metre of precisely measured lengths fully assembled with connecting elements for EMC applications are available from the factory

Specifications

Conduit Profile:
Smooth
Conduit Type:
Regular
Color:
Green
Weight:
0.28 kg
Package quantity:
25 metres

Dimensions:
Conduit OD:
14.0 mm
Conduit ID:
11.0 mm
Static Bend Radius:
50.0 mm
Dynamic Bend Radius:
125 mm

Certifications

EN 50289-1
