M20 x 1.5 mm Metric black FLEXAquick® straight connector for 18.5 mm OD conduit, outer thread

Installs in seconds for Quick "on" assembly, or Quick "off" disassembly.

NO tools required! Makes doing a secure, liquidtight conduit fitting installation, simple, easy, and very quick.

Use with all corrugated plastic conduits of matching outside diameter (OD). Fine ("T" profile) or coarse ("G" profile) corrugations

Need a different size?:  Browse other RQG-M Metric threaded straight fittings

Material:

• plastic PA 6 polyamide nylon body, VO acc. to UL94
• internal seal: TPE rubber

Properties:

• IP 68 / IP 69K sealing level
• Temperature range: -40ºC to +120ºC
• resistant oils and benzene
• widely resistant to acids and solvents
• free of silicone, cadmium, halogen
