RQG-M M32 x 1.5 mm Metric FLEXAquick straight connector for 34.5 mm OD conduit
5020.037.232

Description


M32 x 1.5 mm Metric black FLEXAquick® straight connector for 34.5 mm OD conduit NW 29, outer thread

Installs in seconds for Quick "on" assembly, or Quick "off" disassembly.

NO tools required! Makes doing a secure, liquidtight conduit fitting installation, simple, easy, and very quick.

Use with all corrugated plastic conduits of matching outside diameter (OD). Fine ("T" profile) or coarse ("G" profile) corrugations

Need a different size?:  Browse other RQG-M Metric threaded straight fittings

Material:

  • plastic PA 6 polyamide nylon body, VO acc. to UL94
  • internal seal: TPE rubber

Properties:

  • IP 68 / IP 69K sealing level
  • Temperature range: -40ºC to +120ºC
  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Quick Link to our: Short Form FLEXAquick® Catalogue

Quick Links to other Products:



Specifications

Connector Thread:
M32 x 1.5 mm
Sealing Level:
IP68
Colour:
Black
Weight:
0.024 kg
Package quantity:
25

Dimensions:
φ I:
25.50
φ B:
44.00
C:
15.00
D:
51.00
Conduit OD:
34.5 mm

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
UL1696
UL 1696
#E86359
E162 & 662
SMP800C
EN 45545-2 HL2 for R22 / R 23
45545-2
HL2 Rated
NFF 16-
101/102 I3

Alternate SKU Numbers

796283-8 | 5020-037-232 | 5020037232 | 5020 037 232 | 5020_037_232 | 5020/037/232 | 5020,037,232 | 5020+037+232
