3/4'' NPT FLEXAquick® straight connector for 28.5 mm OD conduit NW 23, outer thread

Features the innovative built-in FLEXAquick® release clip system for easy connector Quick "on" assembly, Quick "off" disassembly

NO tools required! Makes doing a secure, reliable conduit fitting installation, simple, easy, and very quick.

Use with all corrugated plastic conduits of matching outside diameter (OD). Fine ("T" profile) or coarse ("G" profile) corrugations

Need a different size?:  Browse other RQG-N NPT threaded straight fittings

Material:

• plastic PA 6 polyamide nylon body, VO acc. to UL94
• internal seal: TPE rubber

Properties:

• IP 68 / IP 69K sealing level
• Temperature range: -40ºC to +120ºC
• resistant oils and benzene
• widely resistant to acids and solvents
• free of silicone, cadmium, halogen
