RQBK90-N NPT 90° Metal Thead Bend Elbow Connector
5020.022.205

Description


1/2'' NPT FLEXAquick® 90° bend elbow connector, for 15.8 mm OD conduit, outer nickel-plated brass thread, made of polyamide

IP 68 / IP 69K sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide body
  • nickel plated brass outer thread
  • fitting includes "OR" O-ring and "FRH" flat sealing ring

Properties:

  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • excellent for high mechanical stress
  • impact-resistant
  • high-torque tolerant

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® corrugated conduits

Specifications

Connector Thread:
1/2" NPT
Sealing Level:
IP68
Colour:
Black
Weight:
0.03 kg
Package quantity:
50

Dimensions:
φ I:
10.00
φ B:
23.00
C:
12.00
D:
45.40
Conduit OD:
18.5 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
EN 45545-2 HL2 for R22 / R 23
45545-2
HL2 Rated
NFF 16-
101/102 I3
