RQBK90-N NPT 90° Metal Thread Bend Elbow Connector
5020.022.214

Description


3/4'' NPT FLEXAquick® 90° bend elbow connector, for 28.5 mm OD conduit, outer nickel-plated brass thread, made of polyamide

IP 68 / IP 69K sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide body
  • nickel plated brass outer thread
  • fitting includes "OR" O-ring and "FRH" flat sealing ring

Properties:

  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • excellent for high mechanical stress
  • impact-resistant
  • high-torque tolerant

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® corrugated conduits

Specifications

Connector Thread:
3/4" NPT
Sealing Level:
IP68
Colour:
Black
Weight:
0.051 kg
Package quantity:
25

Dimensions:
φ I:
17.00
φ B:
37.00
C:
14.00
D:
64.00
Conduit OD:
28.5

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
EN 45545-2 HL2 for R22 / R 23
45545-2
HL2 Rated
NFF 16-
101/102 I3

Alternate SKU Numbers

5020-022-214 | 5020022214 | 5020 022 214 | 5020_022_214 | 5020/022/214 | 5020,022,214 | 5020+022+214
