RQBK45-P PG 45° Metal Thread Elbow
5020.087.229

Description


PG 29 FLEXAquick® 45° elbow connector, for 34.5 mm OD conduit, outer thread made of nickel-plated brass, body made of polyamide

IP 68 / IP 69K sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide body
  • nickel plated brass outer thread
  • fitting includes "OR" O-ring and "FRH" flat sealing ring

Properties:

  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • excellent for high mechanical stress
  • impact-resistant
  • high-torque tolerant

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® corrugated conduits.



Specifications

Connector Thread:
PG 29
Sealing Level:
IP68
Colour:
Black
Weight:
0.077 kg
Package quantity:
10

Dimensions:
φ I:
29.00
φ B:
44.00
C:
14.00
D:
73.50
Conduit OD:
34.5 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
EN 45545-2 HL2 for R22 / R 23
45545-2
HL2 Rated
NFF 16-
101/102 I3

Alternate SKU Numbers

5020-087-229 | 5020087229 | 5020 087 229 | 5020_087_229 | 5020/087/229 | 5020,087,229 | 5020+087+229
