RQBK90-P PG 90° Metal Thread Bend Elbow Connector
5020.088.248
Description
PG 48 FLEXAquick® 90° bend elbow connector, for 54.5 mm OD conduit, outer nickel-plated brass thread, made of polyamide
IP 68 / IP 69K sealing level
-40ºC to +115ºC
Material:
- plastic PA 6 polyamide body
- nickel plated brass outer thread
- fitting includes "OR" O-ring and "FRH" flat sealing ring
Properties:
- resistant oils and benzene
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- excellent for high mechanical stress
- impact-resistant
- high-torque tolerant
Innovative feature:
- Quick "on" assembly, Quick "off" disassembly via a built-in release clip
Use with ROHRflex® corrugated conduits
Specifications
Connector Thread:
PG 48
Sealing Level:
IP68
Colour:
Black
Weight:
0.218 kg
Package quantity:
5
Dimensions:
φ I:
45.50
φ B:
64.00
C:
17.00
D:
97.00
Conduit OD:
54.5 mm
Datasheet
Certifications

CSA 22.2
# 227.3-05



45545-2
HL2 Rated

NFF 16-
101/102 I3
