RQB90-M Metric Grey 90° Bend Elbow Connector
5103.021.020

Description


M20 x 1.5 mm FLEXAquick® Grey 90° bend elbow connector, for 21.2 mm OD conduit, outer thread

IP 68 / IP 69K sealing level

-40ºC to +115ºC

  • made of polyamide PA 6 plastic
  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® corrugated conduits

Specifications

Connector Thread:
M20 x 1.5 mm
Sealing Level:
IP68
Colour:
Grey
Weight:
0.02 kg
Package quantity:
50

Dimensions:
φ I:
13.00
φ B:
29.50
C:
12.00
D:
48.00
Conduit OD:
21.2 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
EN 45545-2 HL2 for R22 / R 23
45545-2
HL2 Rated
NFF 16-
101/102 I3

Alternate SKU Numbers

5103-021-020 | 5103021020 | 5103 021 020 | 5103_021_020 | 5103/021/020 | 5103,021,020 | 5103+021+020
