RQB90-M Metric Grey 90° Bend Elbow Connector
5103.028.032

Description


M32 x 1.5 mm FLEXAquick® Grey 90° bend elbow connector, for 28.5 mm OD conduit, outer thread

IP 68 / IP 69K sealing level

-40ºC to +115ºC

  • made of polyamide PA 6 plastic
  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® corrugated conduits

Specifications

Connector Thread:
M32 x 1.5 mm
Sealing Level:
IP68
Colour:
Grey
Weight:
0.0356 kg
Package quantity:
25

Dimensions:
φ I:
20.00
φ B:
37.00
C:
14.00
D:
64.00
Conduit OD:
28.5 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
EN 45545-2 HL2 for R22 / R 23
45545-2
HL2 Rated
NFF 16-
101/102 I3

Alternate SKU Numbers

5103-028-032 | 5103028032 | 5103 028 032 | 5103_028_032 | 5103/028/032 | 5103,028,032 | 5103+028+032
