RQG1-N NPT IP66 Straight Connector
5020.046.205
Description
1/2" NPT FLEXAquick® straight connector, for 15.8 mm OD conduit, outer thread
IP 66 sealing level
-40ºC to +115ºC
Material:
- plastic PA 6 polyamide
- VO acc. to UL94
Properties:
- resistant to oils and benzene
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
Innovative feature:
- Quick "on" assembly, Quick "off" disassembly via a built-in release clip
Use with ROHRflex® corrugated conduits
Specifications
Connector Thread:
1/2" NPT
Sealing Level:
IP66
Colour:
Black
Weight:
0.007 kg
Package quantity:
50
Dimensions:
φ I:
12.50
φ B:
25.00
C:
12.00
D:
39.00
Conduit OD:
15.8 mm
Datasheet
Certifications

CSA 22.2
# 227.3-05
