RQG1-N NPT IP66 Straight Connector
5020.046.210

Description


1" NPT FLEXAquick® straight connector, for 34.5 mm OD conduit, outer thread

IP 66 sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide
  • VO acc. to UL94

Properties:

  • resistant to oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® corrugated conduits

Specifications

Connector Thread:
1" NPT
Sealing Level:
IP66
Colour:
Black
Weight:
0.022 kg
Package quantity:
25

Dimensions:
φ I:
27.50
φ B:
44.00
C:
16.00
D:
52.00
Conduit OD:
34.5

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05

Alternate SKU Numbers

5020-046-210 | 5020046210 | 5020 046 210 | 5020_046_210 | 5020/046/210 | 5020,046,210 | 5020+046+210
