RQGZ-N 1/2'' NPT FLEXAquick® Strain Relief Connector for 15.8 mm OD conduit
5704.015.205
Description
1/2" NPT FLEXAquick® straight strain-relief connector for 15.8 mm OD conduit, outer thread
Cable clamping range: 6 - 12.0 mm
IP 68 / IP 69K sealing level
-40ºC to +115ºC
Innovative feature:
- Built-in wire & cable strain-relief system with sealing grommet
- The conduit end of the fitting features a Quick "on" assembly, Quick "off" disassembly via the unique FLEXAquick® built-in release clip system. NO tools required!
Material:
- plastic PA 6 polyamide, nylon
- VO acc. to UL94
Properties:
- resistant to oils and benzene
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- excellent for high mechanical stress
- impact-resistant
Use with ROHRflex® corrugated plastic conduits
Quick Links to other Products:
Specifications
Connector Thread:
1/2" NPT
Sealing Level:
IP68
Colour:
Black
Weight:
0.016 kg
Package quantity:
20
Dimensions:
φ I:
12.00
φ B:
27.00
C:
15.00
D:
69.00
Conduit OD:
15.8 mm
Certifications
CSA 22.2
# 227.3-05
UL 1696
#E86359
E162 & 662
SMP800C
45545-2
HL2 Rated
NFF 16-
101/102 I3
Alternate SKU Numbers
5704-015-205 | 5704015205 | 5704 015 205 | 5704_015_205 | 5704/015/205 | 5704,015,205 | 5704+015+205
