RQGZ-N 3/4'' NPT FLEXAquick® Strain Relief Connector for 28.5 mm OD conduit
5704.028.214

Description


3/4" NPT FLEXAquick® straight strain-relief connector for 28.5 mm OD conduit, outer thread

Cable clamping range: 12 - 18.0 mm

IP 68 / IP 69K sealing level

-40ºC to +115ºC

Innovative feature:

  • Built-in wire & cable strain-relief system with sealing grommet
  • The conduit end of the fitting features a Quick "on" assembly, Quick "off" disassembly via the unique FLEXAquick® built-in release clip system. NO tools required!

Material:

  • plastic PA 6 polyamide, nylon
  • VO acc. to UL94

Properties:

  • resistant to oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • excellent for high mechanical stress
  • impact-resistant

Use with ROHRflex® corrugated plastic conduits

Quick Links to other Products:

Short Form FLEXAquick® NPT Catalogue

Specifications

Connector Thread:
3/4" NPT
Sealing Level:
IP68
Colour:
Black
Weight:
0.034
Package quantity:
10

Dimensions:
φ I:
18.00
φ B:
37.00
C:
15.00
D:
79.00
Conduit OD:
28.5 mm

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
UL1696
UL 1696
#E86359
E162 & 662
SMP800C
EN 45545-2 HL2 for R22 / R 23
45545-2
HL2 Rated
NFF 16-
101/102 I3

Alternate SKU Numbers

5704-028-214 | 5704028214 | 5704 028 214 | 5704_028_214 | 5704/028/214 | 5704,028,214 | 5704+028+214
