RQGZ1-N
5705.015.205
Description
1/2" NPT FLEXAquick® straight strain relief connector, for 15.8 mm OD conduit, outer thread
Cable clamping range: 6 - 12.0 mm
IP 66 sealing level
-40ºC to +115ºC
Material:
- plastic PA 6 polyamide
- VO acc. to UL94
Properties:
- resistant to oils and benzene
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
Innovative feature:
- Quick "on" assembly, Quick "off" disassembly via a built-in release clip
Use with ROHRflex® conduits
Specifications
Connector Thread:
1/2" NPT
Sealing Level:
IP66
Colour:
Black
Weight:
0.016 kg
Package quantity:
20
Dimensions:
φ I:
12.00
φ B:
27.00
C:
15.00
D:
69.00
Conduit OD:
15.8 mm
Certifications
CSA 22.2
# 227.3-05
Alternate SKU Numbers
5705-015-205 | 5705015205 | 5705 015 205 | 5705_015_205 | 5705/015/205 | 5705,015,205 | 5705+015+205
