RQGZ1-N
5705.028.214

Description


3/4" NPT FLEXAquick® straight strain relief connector, for 28.5 mm OD conduit, outer thread

Clamps 12 - 18.0 mm cables

IP 66 sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide
  • VO acc. to UL94

Properties:

  • resistant to oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® conduits

Specifications

Connector Thread:
3/4" NPT
Sealing Level:
IP66
Colour:
Black
Weight:
0.034
Package quantity:
10

Dimensions:
φ I:
18.00
φ B:
37.00
C:
15.00
D:
79.00
Conduit OD:
28.5 mm

Certifications

CSA 22.2
CSA 22.2
# 227.3-05

Alternate SKU Numbers

5705-028-214 | 5705028214 | 5705 028 214 | 5705_028_214 | 5705/028/214 | 5705,028,214 | 5705+028+214
