RQGZ1-N
5705.034.210
Description
1" NPT FLEXAquick® straight strain relief connector, for 34.5 mm OD conduit, outer thread
Clamps 21 - 25.0 mm cables
IP 66 sealing level
-40ºC to +115ºC
Material:
- plastic PA 6 polyamide
- VO acc. to UL94
Properties:
- resistant to oils and benzene
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
Innovative feature:
- Quick "on" assembly, Quick "off" disassembly via a built-in release clip
Use with ROHRflex® conduits
Specifications
Connector Thread:
1" NPT
Sealing Level:
IP66
Colour:
Black
Weight:
0.050 kg
Package quantity:
10
Dimensions:
φ I:
25.00
φ B:
44.00
C:
18.00
D:
89.00
Conduit OD:
34.5 mm
Certifications
CSA 22.2
# 227.3-05
Alternate SKU Numbers
5705-034-210 | 5705034210 | 5705 034 210 | 5705_034_210 | 5705/034/210 | 5705,034,210 | 5705+034+210
