RQW-P PG Grey 90° Elbow Connector
5020.028.016

Description


PG 16 FLEXAquick® Grey 90° elbow connector, for 21.2 mm OD conduit, outer thread

IP 68 / IP 69K sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide
  • VO acc. to UL94

Properties:

  • resistant to oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex®corrugated  conduits

Specifications

Connector Thread:
PG 16
Sealing Level:
IP68
Colour:
Grey
Weight:
0.018 kg
Package quantity:
50

Dimensions:
φ I:
18.00
φ B:
29.50
C:
13.00
D:
48.00
Conduit OD:
21.2 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
EN 45545-2 HL2 for R22 / R 23
45545-2
HL2 Rated
NFF 16-
101/102 I3

Alternate SKU Numbers

969818-4 | 5020-028-016 | 5020028016 | 5020 028 016 | 5020_028_016 | 5020/028/016 | 5020,028,016 | 5020+028+016
