RQGZ-P PG Strain Relief Connector
5020.034.214
Description
PG 13.5 FLEXAquick® straight strain relief connector, for 18.5 mm OD conduit, outer thread
Cable clamping range: 6 - 12.0 mm
IP 68 / IP 69K sealing level
-40ºC to +115ºC
Material:
- plastic PA 6 polyamide
- VO acc. to UL94
- two piece strain relief system with sealing grommet
Properties:
- resistant to oils and benzene
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- excellent for high mechanical stress
- impact-resistant
Innovative feature:
- Quick "on" assembly, Quick "off" disassembly via a built-in release clip
Use with ROHRflex® corrugated conduits
Specifications
Connector Thread:
PG 13.5
Sealing Level:
IP68
Colour:
Black
Weight:
0.016 kg
Package quantity:
10
Dimensions:
φ I:
12.00
φ B:
27.00
C:
8.00
D:
59.00
Conduit OD:
18.5 mm
Datasheet
Certifications
CSA 22.2
# 227.3-05
45545-2
HL2 Rated
NFF 16-
101/102 I3
