LKI-P PG 11 grey plastic swivelling body straight conduit connector for 17.0 mm OD AIRflex conduits
5020.010.011

Description

PG 11 grey plastic swivelling body straight conduit connector for 17.0 mm OD AIRflex conduits, outer thread, made of PP

IP 54 sealing level

-10ºC to +110ºC

Use with the following conduits:

  • Use with all AIRflex® conduits

Unique feature & benefit:

  • once installed, the threaded body of the conduit fitting "swivels", allowing the mounted conduit to rotate freely
  • NO CONDUIT KINKING! It's an ideal terminating solution for AIRflex® conduits in highly active applications like robotics, and machine motion control

Construction

  • Body and compression nut: made of PP polypropylene
  • One piece, two component assembly with a special "twist on" integrated compression nut and ferrule design that locks firmly onto the conduit, while allowing the threaded part to "swivel"

Properties

  • swivielling electrical conduit fitting
  • good dust protection
  • splash proof
  • good vibration tolerance
  • excellent tensile strength

Available also in a smaller 10 piece pack size: Click here for part # 5020.710.011

Quick Links to other Products:

Specifications

Connector Thread:
PG 11
Sealing Level:
IP 54
Colour:
Grey
Weight:
0.0060 kg
Package quantity:
50

Dimensions:
φ I:
11.50
φ B:
24.50
C:
10.00
D:
42.00
Conduit OD:
17.0 mm

Datasheet

PDF iconlki.pdf

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
UL1696
UL 1696
#E86359

Alternate SKU Numbers

5020-010-011 | 5020010011 | 5020 010 011 | 5020_010_011 | 5020/010/011 | 5020,010,011 | 5020+010+011
