PG 36 grey plastic swivelling body straight conduit connector for 45.0 mm OD AIRflex conduits, outer thread, made of PP

IP 54 sealing level

-10ºC to +110ºC

Use with the following conduits:

• Use with all AIRflex® conduits

Unique feature & benefit:

• once installed, the threaded body of the conduit fitting "swivels", allowing the mounted conduit to rotate freely
• NO CONDUIT KINKING! It's an ideal terminating solution for AIRflex® conduits in highly active applications like robotics, and machine motion control

Construction

• Body and compression nut: made of PP polypropylene
• One piece, two component assembly with a special "twist on" integrated compression nut and ferrule design that locks firmly onto the conduit, while allowing the threaded part to "swivel"

Properties

• swivielling electrical conduit fitting
• good dust protection
• splash proof
• good vibration tolerance
• excellent tensile strength

Available also in a smaller 10 piece pack size: Click here for part # 5020.710.036
