RQGST-M Rigid Conduit Adapter
5604.015.216

Description


16 mm FLEXAquick® straight rigid conduit adapter, for 15.8 mm OD conduit, made of polyamide

Adapt 16.0 mm OD rigid conduit to 15.8 mm ROHRflex® flexible corrugated conduit.

IP 68 sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide
  • VO acc. to UL94

Material:

  • plastic PA 6 polyamide
  • VO acc. to UL94

Properties:

  • pipe clamp included
  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® corrugated conduits.

Specifications

Connector Thread:
16 mm rigid
Sealing Level:
IP68
Colour:
Black
Weight:
0.02 kg
Package quantity:
50

Dimensions:
φ I:
12.50
φ B:
23.00
C:
13.00
D:
41.00
Conduit OD:
15.8 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05

Alternate SKU Numbers

5604-015-216 | 5604015216 | 5604 015 216 | 5604_015_216 | 5604/015/216 | 5604,015,216 | 5604+015+216
