RQGST-M Rigid Conduit Adapter
5604.021.220

Description


20 mm FLEXAquick® straight rigid conduit adapter, for 21.2 mm OD conduit, made of polyamide

Adapt 20.0 mm OD rigid conduit to 21.2 mm ROHRflex® flexible corrugated conduit.

IP 68 sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide
  • VO acc. to UL94

Properties:

  • pipe clamp included
  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® corrugated conduits.

Specifications

Connector Thread:
20 mm rigid
Sealing Level:
IP68
Colour:
Black
Weight:
0.025 kg
Package quantity:
50

Dimensions:
φ I:
17.00
φ B:
29.50
C:
13.00
D:
45.00
Conduit OD:
21.2 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05

Alternate SKU Numbers

5604-021-220 | 5604021220 | 5604 021 220 | 5604_021_220 | 5604/021/220 | 5604,021,220 | 5604+021+220
