RQGST-M Rigid Conduit Adapter
5604.028.225

Description


25.0 mm FLEXAquick® straight rigid conduit adapter, for 28.5 mm OD conduit, made of polyamide

Adapt 25.0 mm OD rigid conduit to 28.5 mm ROHRflex® flexible corrugated conduit.

IP 68 sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide
  • VO acc. to UL94

Properties:

  • pipe clamp included
  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® corrugated conduits.

Specifications

Connector Thread:
25 mm rigid
Sealing Level:
IP68
Colour:
Black
Weight:
0.033 kg
Package quantity:
25

Dimensions:
φ I:
20.50
φ B:
37.00
C:
15.00
D:
49.50
Conduit OD:
28.5 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05

Alternate SKU Numbers

5604-028-225 | 5604028225 | 5604 028 225 | 5604_028_225 | 5604/028/225 | 5604,028,225 | 5604+028+225
