RQGST-M Rigid Conduit Adapter
5604.034.232

Description


32.0 mm FLEXAquick® straight rigid conduit adapter, for 34.5 mm OD conduit, made of polyamide

Adapt 32.0 mm OD rigid conduit to 34.5 mm ROHRflex® flexible corrugated conduit.

IP 68 sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide
  • VO acc. to UL94

Properties:

  • pipe clamp included
  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen

Innovative feature:

  • Quick "on" assembly, Quick "off" disassembly via a built-in release clip

Use with ROHRflex® corrugated conduits.



Specifications

Connector Thread:
32 mm rigid
Sealing Level:
IP68
Colour:
Black
Weight:
0.0392 kg
Package quantity:
25

Dimensions:
φ I:
25.50
φ B:
44.00
C:
15.00
D:
52.50
Conduit OD:
34.5 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05

Alternate SKU Numbers

5604-034-232 | 5604034232 | 5604 034 232 | 5604_034_232 | 5604/034/232 | 5604,034,232 | 5604+034+232
