RQGST-M Rigid Conduit Adapter
5604.042.240
Description
40.0 mm FLEXAquick® straight rigid conduit adapter, for 42.5 mm OD conduit, made of polyamide
Adapt 40.0 mm OD rigid conduit to 42.5 mm ROHRflex® flexible corrugated conduit.
IP 68 sealing level
-40ºC to +115ºC
Material:
- plastic PA 6 polyamide
- VO acc. to UL94
Properties:
- pipe clamp included
- resistant oils and benzene
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
Innovative feature:
- Quick "on" assembly, Quick "off" disassembly via a built-in release clip
Use with ROHRflex® corrugated conduits.
Specifications
Connector Thread:
40 mm rigid
Sealing Level:
IP68
Colour:
Black
Weight:
0.0552 kg
Package quantity:
25
Dimensions:
φ I:
32.00
φ B:
52.00
C:
16.50
D:
54.50
Conduit OD:
42.5 mm
Datasheet
Certifications

CSA 22.2
# 227.3-05



Alternate SKU Numbers
5604-042-240 | 5604042240 | 5604 042 240 | 5604_042_240 | 5604/042/240 | 5604,042,240 | 5604+042+240
