RQGST-M Rigid Conduit Adapter
5604.054.250
Description
50.0 mm FLEXAquick® straight rigid conduit adapter, for 54.5 mm OD conduit, made of polyamide
Adapt 50.0 mm OD rigid conduit to 54.5 mm ROHRflex® flexible corrugated conduit.
IP 68 sealing level
-40ºC to +115ºC
Material:
- plastic PA 6 polyamide
- VO acc. to UL94
Properties:
- pipe clamp included
- resistant oils and benzene
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
Innovative feature:
- Quick "on" assembly, Quick "off" disassembly via a built-in release clip
Use with ROHRflex® corrugated conduits.
Specifications
Connector Thread:
50 mm rigid
Sealing Level:
IP68
Colour:
Black
Weight:
0.059 kg
Package quantity:
10
Dimensions:
φ I:
42.50
φ B:
64.00
C:
17.00
D:
55.50
Conduit OD:
54.5 mm
Datasheet
Certifications

CSA 22.2
# 227.3-05
