ROHRflex® PA12 Grey Corrugated Conduit
0236.201.016

Description


OD 21.2 mm ROHRflex® - PA 12 Grey Polyamide all plastic standard-walled, fine profile tubing. Corrugated internally & externally.

V2 [UL94]

-50ºC to +100ºC ... short term to +150ºC

Properties:

  • high alternate bending strength
  • air and liquid-tight
  • oil and benzene resistant
  • widely resistant to acids, solvents and cutting fluids
  • free of silicone, cadmium, halogen
  • self-extinguishing and flame retardant
  • black version conduits are UV resistant and stabilized

Applications:

  • excellent for railway applications, especially exterior wiring
  • excellent for robotics and high motion applications
  • shipbuilding and general machine / automation wiring

Use with all FLEXAquick® fittings and connectors

Specifications

Conduit Profile:
Fine
Conduit Type:
Regular
Color:
Grey
Weight:
0.06 kg
Package quantity:
50 metres

Dimensions:
Conduit OD:
21.2 mm
Conduit ID:
16.5 mm
Static Bend Radius:
35 mm
Dynamic Bend Radius:
75 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
E162 & 662
SMP800C
NFF 16-
101/102 I3

Alternate SKU Numbers

969792-4 | 0236-201-016 | 0236201016 | 0236 201 016 | 0236_201_016 | 0236/201/016 | 0236,201,016 | 0236+201+016
