RQF2-M Grey Flange Adapter
5020.071.032

Description


M32 x 1.5 mm FLEXAquick® Grey Flange Adapter, made of polyamide

Adds a flange to any M32 male thread FLEXAquick® fitting

IP 68 sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide

Properties:

  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • flame resistant
  • self-extinguishing, in case of fire

Excellent for mounting to control panels and applications in tight areas.

Use with FLEXAquick® fittngs and connectors.

Specifications

Connector Thread:
M32 x 1.5 mm
Sealing Level:
IP68
Colour:
Grey
Weight:
0.0148 kg
Package quantity:
25

Dimensions:
φ I:
28.00
φ B:
63.00
C:
46.00
D:
52.00
Conduit OD:
28.5 mm / 34.5 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
