RQF2-M Flange Adapter
5020.071.225

Description


M25 x 1.5 mm FLEXAquick Flange Adapter, made of polyamide

Adds a flange to any M25 male thread FLEXAquick fitting

IP 68 sealing level

-40ºC to +115ºC

Material:

  • plastic PA 6 polyamide

Properties:

  • resistant oils and benzene
  • widely resistant to acids and solvents
  • free of silicone, cadmium, halogen
  • flame resistant
  • self-extinguishing, in case of fire

Excellent for mounting to control panels and applications in tight areas.

Use with FLEXAquick® fittngs and connectors.

Specifications

Connector Thread:
M25 x 1.5 mm
Sealing Level:
IP68
Colour:
Black
Weight:
0.0066 kg
Package quantity:
50

Dimensions:
φ I:
21.00
φ B:
46.00
C:
32.00
D:
36.00
Conduit OD:
21.2 mm / 28.5 mm

Datasheet

Certifications

CSA 22.2
CSA 22.2
# 227.3-05
