RQF2-M Flange Adapter
5020.071.250
Description
M50 x 1.5 mm FLEXAquick® Flange Adapter, made of polyamide
Adds a flange to any M50 male thread FLEXAquick® fitting
IP 68 sealing level
-40ºC to +115ºC
Material:
- plastic PA 6 polyamide
Properties:
- resistant oils and benzene
- widely resistant to acids and solvents
- free of silicone, cadmium, halogen
- flame resistant
- self-extinguishing, in case of fire
Excellent for mounting to control panels and applications in tight areas.
Use with FLEXAquick® fittngs and connectors.
Specifications
Connector Thread:
M50 x 1.5 mm
Sealing Level:
IP68
Colour:
Black
Weight:
0.025 kg
Package quantity:
10
Dimensions:
φ I:
42.50
φ B:
86.00
C:
64.00
D:
73.00
Conduit OD:
42.5 mm / 54.5 mm
Datasheet
Certifications

CSA 22.2
# 227.3-05
